Description
ORION II 180 V are six to nine semi-mounted reversible ploughs designed for tractors with a power of 180 hp and above. During the design, emphasis was placed on quality workmanship combined with a long service life of all components. The main frame of the plough is made of a high-strength profile 180 x 180 x 10 mm, which gives the plough rigidity and durability. We also use the most durable materials for other parts of the plough, which we further refine in production to achieve a quality product with high utility value.
-
Turn of plough with telescopic pistons
-
Adjusting the engagement of the 1st blade
-
Hydro pneumatically sprung transport wheel
-
Mechanical adjustment of blade engagement
-
Cat. 3/4 hitch
-
Main Advantages
The basic frame of the machine is made up of a 6+1 modular system; 7+1 and 8+1. The system thus allows you to assemble the machine according to your current needs. The plow can therefore be extended as well as shortened at any time, which is an advantage, for example, when exchanging tractors with different outputs. The width adjustment is carried out continuously by the hydraulic Vario system.
Technical Parmeters
Technical Parameters |
ORION II 180 V |
|||
| Number of Ploughshares (pc) | 6 | 7/6+1 | 8/7+1 | 9/8+1 |
| Working Width of One Body (cm) | 33-50 | 33-50 |
33-50 |
33-50 |
| Plough Full Working Width (cm) | 180-330 | 210-385 | 240-440 | 270-495 |
| Clearance under the Frame (cm) | 82 | 82 | 82 | |
| Spacing between the Ploughs (cm) | 100 | 100 | 100 | 100 |
| Operating Speed (Km/hr.) | 7 | 7 | 7 | 7 |
| Plough Weight* | ||||
| Shear (kg) | 3,410 | 3,720 | 4,070 | 4,430 |
| Spring (kg) | 4,830 | 4,210 | 4,670 | 5,160 |
| Tractor Output (Hp) | 180-270 | 210-315 | 240-380 | 270-430 |
** Only for variants with shear hub protection of the ploughshares.
** The weight is only indicative and may vary according to the selected machine.
